BLT310 Product Manual
1
1.Product Description
1.1 Product View
Product View (Structure and Interface Description)
1. Optical fiber interface; 8. Cutting gas interface;
2. 1
st
Upper protective lens; 9. Cooling water outlet;
3. Collimation unit; 10. Nozzle cooling gas inlet;
4. Focusing unit; 11. Cooling water inlet
5. 2
nd
Lower protective lens; 12. Anti-collision screw;
6. 1
st
Lower protective lens; 13. Ceramic body lock ring;
7. Working indicator; 14. Ceramic body;
15. Nozzle
1
4
2
3
5
6
7
8
9
12
11
10
13
14
15
