Bodet Style 7 Date - Page 12

12
DHF synchronisation card
AFNOR synchronisation card
EN
Connector available for Style 5S
and 10S only (timer mode)
Refer to the keypad instructions
(supplied with the keypad)
Neutral (blue)
Phase (brown)
Polarity is
irrelevant to
the network
Neutral (blue)
(black)
(red)
Phase (brown)
Connector for control keypad
Refer to the keypad instructions
(supplied with the keypad)
