STEP
21
51
Selector Rod Top Bolt
WARNING
! !
Selector Rod Top Bolt (52) Must be threaded a
minumum of a 1/2” into the Selector Rod(6),
and Lock Nut (54) tightened securely to ensure
proper connection.
NOTE 2
Check lock nut
weekly to be
sure it is tight
and locked on
to the Selector
Rod.
(See page 61)
NOTE 1
Before beginning final cable
adjustments, be sure that both of
these pulley housings butt-up as
close as possible to the welded
stops on the frame pieces.
B. Rubber Stop (42)
Tighten
To Next Page
