22
STEP
53
NOTE 2
This is the top view of the four Weight Stack Shrouds. Note the
shape of each shroud for proper placement.
NOTE 1
Apply weight stack numbers to the Weight
Stack Plates (51). Start at the Top Plate (8) with
the number 1, and the first plate should be
number 2. The following Weight Stack Plates
(51) should be numbered in sequential order
down through the stack.
2” flat side3/4” flat side
3/4” flat side
To Next Page
