Adjust
Seated Press
Arm (AC)
Pull Ball Head
Pop Pin (57)
1.
2.
3.
top Ball Head
Pop Pin (56)
side Ball Head
Pop Pin (56)
Adjust
Upper Back
Pad (ZA)
Pull T-Shaped
Pop Pin (48)
Pay special attention to the plunger on this Pop Pin (48).
Always be sure that the plunger is fully engaged
into the hole
you select. Also, be sure that the spring in the Pop Pin (48)
operates freely. Failure to do so may result in serious injury.
WARNING
! !
Make sure Pop Pin (48) is fully
engaged into selector hole, and then
turn clockwise to lock it in place.
55
(Reverse view drawing)
Leg Extension
Seat Pad (V)
To Next Page
