Pull Ball Head
Pop Pin (50)
Adjust Pec Dec
Arm (AK) or (AP)
Make sure Pop Pin is fully
engaged into selector
hole, and then turn clockwise to lock it in place.
Pull T-Shaped
Pop Pin (48)
Pull T-Shaped
Pop Pin (48)
Make sure Pop Pin is fully
engaged into selector
hole, and then turn clockwise to lock it in place.
Pay special attention to the plunger on this Pop Pin (48).
Always be sure that the plunger is fully engaged
into the hole
you select. Also, be sure that the spring in the Pop Pin (48)
operates freely. Failure to do so may result in serious injury.
WARNING
! !
Pay special attention to the plunger on this Pop Pin (48).
Always be sure that the plunger is fully engaged
into the hole
you select. Also, be sure that the spring in the Pop Pin (48)
operates freely. Failure to do so may result in serious injury.
WARNING
! !
57
5.
(Reverse view drawing)
6.
4.
