Body Solid G9S - Page 97

EXM3700GLPS Hardware
(continued)
KEY# QTY PART# DESCRIPTION
JHEX.5X5.5PTB
JHEX.5X5.25PTB
JHEX.5X5PTB
JHEX.5X3.5PTB
JHEX.5X3.25PTB
JHEX.5X3PTB
JHEX.5X1.75FTB
JHEX.37X3.5PTB
JHEX.37X3.25PTB
JHEX.37X3PTB
JHEX.37X2.75PTB
JHEX.37X2.5PTB
JHEX.37X2PTB
JHEX.37X1.75PTB
JFAH.37X2FTB
JHEX.37X.87FTB
JHEX.31X5PTB
JHEX.31X3.25PTB
JHEX.31X2.75FTB
JHEX.31X1FTB
JFAH.31X1.5FTB
JFAH.31X.75FTB
JRAH.31X.56FTB
JRAH.37X.62FTB
JAS.31X.31FT
JRAH.31X.75FTB
JNLN.5
JNLN.37
JNLN.31
JWFLT.5
JWFLT.37
JWFLT.31
JWSW.31
JWFLT.31
JWFLT.37
JAS.19X.19
JCEC1.37X1
JRR1.5X1.25
JBB1.75X1
JBB.87x.62
JCC1.43X1
JBB1.75X1
JACN.19
JHEX.37X1FTB
JLN.37
JSB1.75X1
JRR1.75X1.5
JCES
JAS
Part numbers are required when ordering parts.
95
60
61
62
63
64
65
66
70
71
72
73
74
75
76
77
78
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
101
102
103
104
105
106
107
108
112
113
114
115
135
136
1
3
2
1
9
4
4
1
2
3
18
1
2
21
2
2
2
1
6
10
1
4
6
9
14
4
21
50
1
43
90
23
23
4
9
4
2
2
2
2
2
12
2
2
2
2
2
2
2
HEX HEAD BOLT 1/2” X 5 1/2” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 5 1/4” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 5” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 3 1/2” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 3 1/4” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 3” PARTIAL THREAD
HEX HEAD BOLT 1/2” X 1 3/4” FULL THREAD
HEX HEAD BOLT 3/8” X 3 1/2” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 3 1/4” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 3” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 2 3/4” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 2 1/2” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 2” PARTIAL THREAD
HEX HEAD BOLT 3/8” X 1 3/4” PARTIAL THREAD
FLAT ALLEN HEAD 3/8” X 2” FULL THREAD
HEX HEAD BOLT 3/8” X 7/8” FULL THREAD
HEX HEAD BOLT 5/16” X 5” PARTIAL THREAD
HEX HEAD BOLT 5/16” X 3 1/4” PARTIAL THREAD
HEX HEAD BOLT 5/16” X 2 3/4” FULL THREAD
HEX HEAD BOLT 5/16” X 1” FULL THREAD
FLAT ALLEN HEAD 5/16” X 1 1/2” FULL THREAD
FLAT ALLEN HEAD 5/16” X 3/4” FULL THREAD
ROUND ALLEN HEAD 5/16” X 9/16” FULL THREAD (8mmX15mm)
ROUND ALLEN HEAD 3/8” X 5/8” FULL THREAD (10mmX16mm)
ALLEN SCREW 5/16” X 5/16” FULL THREAD
ROUND ALLEN HEAD 5/16” X 3/4” FULL THREAD
NYLON LOCK NUT 1/2”
NYLON LOCK NUT 3/8”
NYLON LOCK NUT 5/16”
WASHER 1/2”
WASHER 3/8”
WASHER 5/16”
SPRING LOCK WASHER 5/16”
WASHER 5/16” (8mm shrouds)
WASHER 3/8” (10mm shrouds)
ALLEN SCREW 3/16” X 3/16” -PREINSTALLED
CHROME END CAP 1 3/8”OD X 1”ID X 3/4”L- PREINSTALLED
RETAINING RING 1 1/2” OD X 1 1/4”ID (leg ext)-PREINSTALLED
OILITE BUSHING 1 3/4”OD 1”ID - PREINSTALLED (seated press)
OILITE BUSHING 7/8”OD 5/8”ID - PREINSTALLED (low row)
CHROME COLLAR 1 7/16” OD X 1” ID
OILITE BUSHING 1 3/4”OD 1”ID - PREINSTALLED (pec dec)
ACORN CAP NUT 3/16” ID - PREINSTALLED
HEX HEAD BOLT 3/8” X 1” FULL THREAD (adjustment bolt)
LOCK NUT 3/8”
STEEL BUSHING 1 3/4”OD 1” ID - PREINSTALLED (seated press)
RETAINING RING - 1 3/4”OD 1” ID -PREINSTALLED (seated press)
CABLE END SHAFT 3/4” L
ALLEN SCREW 1/8” X 1/4”(4mm X 8mm)
