14
S T E P
3
Be careful to assemble all components
in the sequence they are presented.
NOTE: Two people are required to assemble this section.
Tighten all hardware at the end of this step.
A. Connect Right Glide Frame (F) to Right Stabilizer Frame (C) using:
Two 1 (M12x75 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
B. Connect Left Glide Frame (G) to Left Stabilizer Frame (D) using:
Two 1 (M12x75 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
C. Attach Rubber Pads (35) into Left Glide Frame (G) and Right Glide Frame (F).
NOTE: Secure Rubber Pads (35) as shown in the diagram.
D. Slide Carriage (H) into Left Glide Frame (G) and Right Glide Frame (F).
NOTE: Carriage (H) is extremely heavy. Two people are required for this installation.
E. Insert two Foot Caps (32) into Base Cross Bar (E).
F. Connect Upright (B) to Base Cross Bar (E) and Base Frame (A) using:
Two 2 (M12x80 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
G. Connect Cross Bar (AD) to Upright (B) using:
Two 4 (M12x125 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
H. Secure Left Glide Frame (G) and Right Glide Frame (F) to Cross Bar (AD) using:
Two 5 (M12x135 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
