Body Solid GLPH1100 - Dimensions

D i m e n s i o n s
6
The room layout diagram below will help you decide the best placement for your GLPH1100.
The dimensions of the GLPH1100 are: Width 2’ 11” X Length 7’8”.
The ceiling height requirement for the GLPH1100 is 4’7”.
The usage space is: Width 5’ X Length 10’ (The usage space is the overall space needed for operation).
The usage space needed for the GLPH1100 could be more, depending on the user.
Minimum Usage Space
2’ 11”
7’ 8”
4’ 7”
Suggested Usage Space
10’
5’
G L P H 1 1 0 0
R e f e r e n c e D r a w i n g s
