M a i n f r a m e P a r t s L i s t
Part# Qty Description
A 1 BASE FRAME
B 1 UPRIGHT
C 1 RIGHT STABILIZER FRAME
D 1 LEFT STABILIZER FRAME
E 1 BASE CROSS BAR
F 1 RIGHT GLIDE FRAME
G 1 LEFT GLIDE FRAME
H 1 CARRIAGE
J 1 WEIGHT HORN BAR
K 1 ADJUSTABLE PLATE
L 1 RIGHT ADJUST BAR
M 1 LEFT ADJUST BAR
N 1 SELECTOR INSERT FRAME
O 1 SELECTOR TUBE
P 2 SLIDE TUBE
Q 1 LEFT ARM
R 1 RIGHT ARM
S 1 FOOT PLATE
T 1 LEFT LOWER MOUNT FRAME
U 1 RIGHT LOWER MOUNT FRAME
V 1 SUPPORT PLATE (8312-013)
W 2 PAD FRAME (8343-023)
X 1 WEIGHT HORN BAR SUPPORT PLATE (8333-045)
Y 1 UPPER PAD (9112-026)
Z 1 HEAD REST PAD (9132-016)
AA 1 LOWER PAD (9112-025)
AB 2 ARM PAD (9132-002)
AC 1 MIDDLE PAD (9122-031)
AD 1 CROSS BAR
Part numbers are required when ordering parts.
