H a
d w a
e
L
i
s
t
( c o n t i n u e d )
Part# Qty Description
1 4 HEX HEAD BOLT M12x75
2 6 HEX HEAD BOLT M12x80
3 4 HEX HEAD BOLT M12x90
4 3 HEX HEAD BOLT M12x125
5 2 HEX HEAD BOLT M12x135
6 2 HEX HEAD BOLT M10x20
7 4 HEX HEAD BOLT M10x75
8 4 HEX HEAD BOLT M8x20
9 4 ALLEN PAN HEAD BOLT
5/16
” x 1”
10 13 ROUND ALLEN HEAD BOLT
5/16
” x 1”
11 2 HEX HEAD BOLT
5/16
” x 1
1/4
”
12 2 HEX HEAD BOLT
5/16
” x 2
1/4
”
13 2 ALLEN SCREW M8X8
- PREINSTALLED
14 4 ROUND ALLEN HEAD BOLT M8x30 - PREINSTALLED
15 4 ALLEN SCREW M5x5 - PREINSTALLED
16 1 POP PIN M31.5x115L (8250-033) - PREINSTALLED
17 1 POP PIN M22x78L (8250-033) - PREINSTALLED
18 19 NYLON LOCK NUT M12
19 4 NYLON LOCK NUT M10
20 8 NYLON LOCK NUT M8
21 8 WASHER M12 ID 25MM OD
22 30 WASHER M12 ID 34MM OD
24 10 WASHER M10 ID 27MM OD
25 17 WASHER M8 ID 24MM OD
26 25 SPRING WASHER M8
27 12 WASHER M8 ID 18MM OD
28 2 END CAP M45x45 (9211-091)
29 3 END CAP 2” x 2” (9211-006)
30 4 END CAP 2” x 2” (9211-087)
31 2 ROUND END CAP Ø50 (9211-020)
32 7 FOOT CAP 2” x 2” (9211-024)
33 8 ROUND END CAP Ø20 (9211-036)
34 2 BASE CAP 2” x 2” (9212-010)
35 2 RUBBER PAD M38x75 (9310-002)
36 1 RUBBER PAD M38x325 (9310-042)
37 4 ROUND END CAP 1” x 2.5T (9260-021)
38 4 END CAP M38x38 (9211-003)
39 2 END CAP M25x50 (9211-009)
40 8 BEARING (8510-002)
- PREINSTALLED
41 2 COPPER SPACER (8520-013)
42 4 CONVEXITY LOOP (9213-050)
- PREINSTALLED
43 2 CHROME COLLAR Ø35xØ26X19L (8890-061) - PREINSTALLED
44 2 FOAM GRIP (9162-010) - PREINSTALLED
45 1 TORSION SPRING (8840-044) - PREINSTALLED
46 1 TORSION SPRING (8840-045) - PREINSTALLED
47 2 BAFFLE WALL (9310-018) - PREINSTALLED
48 1 SHAFT
Ø
3/4
” x 410L (8210-044) - PREINSTALLED
49 8 C-CLIP
50 2 BODY SOLID LOGO (9440-028)
- PREINSTALLED
51 1 BODY SOLID PLATE (9440-199) - PREINSTALLED
52 2 POP PIN STICKER (9440-104) - PREINSTALLED
53 1 MAINTENANCE LABEL (9440-103) - PREINSTALLED
54 1 GENERAL WARNING STICKER (9440-105) - PREINSTALLED
55 1 SELECTOR STICKER (9440-066) - PREINSTALLED
56 1 CAUTION STICKER (9440-220) - PREINSTALLED
57 1 WEIGHT HORN WARNING STICKER (9440-217) - PREINSTALLED
58 1 PLATE DANGER STICKER (9440-208) - PREINSTALLED
59 4 FOAM GRIP (9162-002) - PREINSTALLED
60 4 PU WHEEL (9213-044) - PREINSTALLED
Part numbers are required when ordering parts.
55
