Body Solid GLPH1100 - Torsion Spring Removal

G L P H 1 1 0 0
T o r s i o n S p r i n g R e m o v a l
Remove the two Set Screws
(13).
•
Remove the M12x135 Hex
Head Bolt (5) as shown.
or if Shaft (48) is not
threaded as shown in
the gure, skip this step .
•
Thread the M12x135 Hex
Head Bolt (5) onto Shaft (48)
and leave it nger tight.
or if Shaft (48) is not
threaded, then use a
punch or other tool that
can be used to push out
Shaft (48).
•
48
