S T E P
5
Be careful to assemble all components
in the sequence they are presented.
NOTE: Tighten all hardware at the end of this step.
A. Connect Upper Pad (Y) to Adjustable Plate (K) using:
Four 9 (⁄” x 1” allen pan head bolt)
NOTE: Do not over tighten Pad Bolts (9), over tightening will strip the T-nuts pressed into
the wood.
B. Attach Rubber Pad (36) to Lower Pad (AA).
NOTE: See figure on next page for a detailed view.
C. Slide Left Lower Mount Frame (T) and Right Lower Mount Frame (U) onto the rod on Foot Plate (S)
and secure Left Lower Mount Frame (T) and Right Lower Mount Frame (U) onto Lower Pad (AA)
using:
Four 10 (⁄” x 1” round allen head bolt)
Four 26 (M8 spring washer)
Four 25 (M8 washer)
NOTE: Do not over tighten Pad Bolts (10), over tightening will strip the T-nuts pressed into
the wood.
