22
S T E P
7
Be careful to assemble all components
in the sequence they are presented.
NOTE: Tighten all hardware at the end of this step.
A. Insert End Cap (29) into Weight Horn Bar (J).
B. Insert two Round End Caps (31) into Weight Horn Bar (J).
C. Connect Weight Horn Bar (J) and Weight Horn Bar Support Plate (X) to Carriage (H) using:
Two 2 (M12x80 hex head bolt)
Four 22 (M12 washer)
Two 18 (M12 nylon lock nut)
D. Secure Weight Horn Bar (J) to Carriage (H) by adding:
One 4 (M12x125 hex head bolt)
Two 22 (M12 washer)
One V (Support Plate)
One 18 (M12 nylon lock nut)
E. Connect Arm Pad (AB) and Pad Frame (W) to Left Arm (Q) using:
Four 10 (⁄” x 1” round allen head bolt)
Four 26 (M8 spring washer)
Four 27 (M8 washer)
NOTE: Do not over tighten Pad Bolts (10), over tightening will strip the T-nuts pressed into
the wood.
F. Connect Arm Pad (AB) and Pad Frame (W) to Right Arm (R) using:
Four 10 (⁄” x 1” round allen head bolt)
Four 26 (M8 spring washer)
Four 27 (M8 washer)
NOTE: Do not over tighten Pad Bolts (10), over tightening will strip the T-nuts pressed into
the wood.
