BOGE Operating instructions for C 10 L...C 20 L series screw compressors Page 9
Product description 2.1 Technical data
Part 2: Product description 2.1 Technical data
Technical data for C 10 L...C 20 L compressor assembly, part 1
Type C 10 L C 15 L C 20 L
Dimensions
– Width [inch] 46.1 52.5 52.5
– Depth [inch] 23.6 24.2 24.2
– Height [inch] 23.4 25.3 25.3
Weight
– silenced [lbs.] 313.2 361.4 361.4
Max. sound pressure level [± 3 dB(A)]
accord. to DIN 45635, part 13
– silenced / super silenced [dB(A)] 68 75 75
Reference surface measure
– silenced / super silenced [dB(A)] 13 13 13
Sound power level
– silenced / super silenced [dB(A)] 81 88 88
Compressor
max. final compression temperature [°F] 230 230 230
Volume flow according to
ISO 1217 appendix C at:
– p
max
= 115 psig [cfm] – 69 –
– p
max
= 150 psig [cfm] 36 – 77
Drive motor
Rated power [Hp] 10 15 20
Nominal speed
– 60 Hz [min
-1
] 1800 3600 3600
Protection type TEFC TEFC TEFC
ISO class F F F
Electrical connection
Mains voltage
1)
[V]
Frequency
1)
[Hz]
Recommended fuse protection
2) 3)
[A]
1)
Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
2)
The fuse values change in the case of other mains voltages and frequencies.
3)
Use fuse Class RK 5 only.
200
60
40
200
60
70
200
60
70
Mains voltage
1)
[V]
Frequency
1)
[Hz]
Recommended fuse protection
2) 3)
[A]
208 – 230
60
40
208 – 230
60
60
208 – 230
60
60
Mains voltage
1)
[V]
Frequency
1)
[Hz]
Recommended fuse protection
2) 3)
[A]
460
60
25
460
60
30
460
60
30
Mains voltage
1)
[V]
Frequency
1)
[Hz]
Recommended fuse protection
2) 3)
[A]
575
60
15
575
60
30
575
60
30
