BOGE Operating instructions for C 15 series screw compressors Page 15
Product description 2.1 Technical data – compressor
Part 2: Product description 2.1 Technical data – compressor
Technical data C 15 / C 15 F, part 1
Type C 15 C 15 F
Dimensions
– Width [inch] 28.4 28.4
– Depth [inch] 39 39
– Height (super silenced) [inch] 68.3 68.3
Weight
– super silenced [lbs.] 904 961
Max. sound pressure level [±3 dB(A)]
– super silenced [dB(A)] 67 67
Reference surface measure
– super silenced [dB(A)] 16 16
Sound power level
– super silenced [dB(A)] 83 83
Compressor
max. final compression temperature [°F] + 230 + 230
Volume flow
– p
max
= 100 psig [cfm] 61.4 61.4
– p
max
= 115 psig [cfm] 61.4 61.4
– p
max
= 150 psig [cfm] 54.0 54.0
– p
max
= 190 psig [cfm] 47.0 47.0
Drive motor
Rated power [Hp] 15 15
Nominal speed
– 60 Hz [rpm] 3600 3600
Protection type TEFC TEFC
ISO class F F
Electrical connection
Mains voltages compressor
1)
[V] 208-230 / 460 / 575 208-230 / 460 / 575
Frequency
1)
[Hz] 60 60
Fuse protection for 208 V
2) 3)
[A] 60 60
Fuse protection for 230 V
2) 3)
[A] 60 60
Fuse protection for 460 V
2) 3)
[A] 30 30
Fuse protection for 575 V
2) 3)
[A] 30 30
1)
Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
2)
The fuse values change in the case of other mains voltages and frequencies.
3)
Use fuse Class RK 5 only.
