Product description 2.2 Function description compressor
Page 16 BOGE Operating instructions for C 15 series screw compressors
Technical data C 15 / C 15 F, part 2
2.2 Function description compressor
Function principle of the
air end
The air end operates according to the displacement principle. In the housing,
the main and secondary screws are driven by means of an electric motor and
V-belts.
Both screws have screw-shaped profiles, intermeshing without contact. To-
gether with the housing wall, these screws form chambers which gradually
reduce in size, seen in air flow direction.
Type C 15 C 15 F
Oil filling quantity
Total oil filling quantity [gallon] 1.6 1.6
Oil topping up quantity
between min. + max. [gallon] 0.3 0.3
Intake air temperature
– min. [°F] + 41 + 41
– max. [°F] + 113 + 113
Air cooling
Cooling air requirement
– free-standing installation [cfm] 2180 2180
– with supply and exhaust air duct [cfm] 1002 1002
– free ventilator pressure [Pa] 60 60
– free ventilator pressure [inch Hg] 0.203 0.203
Operating pressure values
1)
(factory settings)
– p
max
= 100 psig:switch-off pressure p
max
[psig] 100 100
switch-on pressure p
min
[psig] 85 94
– p
max
= 115 psig:switch-off pressure p
max
[psig] 115 115
switch-on pressure p
min
[psig] 100 109
– p
max
= 150 psig:switch-off pressure p
max
[psig] 150 150
switch-on pressure p
min
[psig] 135 144
– p
max
= 190 psig:switch-off pressure p
max
[psig] 190 190
switch-on pressure p
min
[psig] 175 184
Safety valve
Activation pressure at:
– p
max
= 100 psig [psig] 160 160
– p
max
= 115 psig [psig] 160 160
– p
max
= 150 psig [psig] 160 160
– p
max
= 190 psig [psig] 203 203
1)
For fixed compressors with other operating pressures p
min
= p
max
– 15 psig, for frequency controlled compressors with other operating pressures p
min
= p
max
– 6 psig.
