BOGE Operating instructions for C 15 series screw compressors Page 61
Maintenance 6.3 Maintenance work compressor
Fig. 6.10: Lock nut on safety valve
Nozzle with dirt catch
Change:
After 3000 operating hours, however, no later than after one year.
Switch off the compressor using the OFF button.
Close ball valve at the compressed air outlet.
Open safety sound insulation hood.
Vent the compressor (as described in the beginning of the chapter).
Wait approx. 3 minutes to permit the oil to settle.
Unscrew nozzle with dirt catch (see arrow) (1).
Screw in new nozzle with dirt catch.
Fig. 6.11: Nozzle with dirt catch
Open the threaded plug
(see arrow) anticlock-
wise. The air/oil mixture
escapes.
Tighten the threaded plug
by turning clockwise.
WARNING!
If the prescribed maintenance interval is not observed, the residual oil con-
tent in the compressed air increases considerably.
WARNING: Risk of injury!
Prior to any maintenance and servicing work take all necessary safety pre-
cautions described on page 44!
