BOGE Operating instructions for C 15 series screw compressors Page 55
Maintenance 6.3 Maintenance work compressor
Changing the oil filter
(Fig. 6.6)
Change:
After 3000 operating hours, however, no later than after one year.
With each oil change!
Switch off the compressor using the OFF button.
Slacken screws on service cover and remove cover (see arrows in figure
6.6).
Take out oil filter cartridge (4) and remove from support body (5) (see fig-
ure 6.6).
Slide support body into the new oil filter cartridge.
Fit oil filter cartridge (4) with support body (5).
Check o-rings on service cover for damage and replace if necessary.
Fit service cover (3) and tighten screws (see arrows in figure 6.6).
Open the ball valve at the compressed air outlet.
Switch on the compressor and heat up to operating temperature.
Check tightness of service cover and re-tighten screws.
Close sound insulation hood
WARNING!
When using mineral oil or oil suitable for the foodstuff industry: Change oil
filter after the first 500 operating hours!
WARNING: Risk of injury!
Prior to any maintenance and servicing work take all necessary safety pre-
cautions described on page 44!
Close ball valve at the compressed air outlet.
Vent the compressor (as described in the beginning of the chapter).
Open safety sound insulation hood.
Wait approx. 3 minutes to permit the oil to settle.
WARNING: Risk of injury!
Hot surfaces: Do not touch!
WARNING!
Over-current / Non-return valve (6) must be fitted facing up.
