Operating instructions for S 40-3...S 150-3 series screw compressors Page 15
Product description 2.1 Technical data
Part 2: Product description 2.1 Technical data
Technical data S 40-3...S 100-3, part 1
Type S 40-3 S 50-3 S 60-3 S 61-3 S 75-3 S 100-3
Dimensions
- Height (silenced) [inch] 57.0 57.0 57.0 57.2 57.2 57.2
- Height (super silenced) [inch] - 76.5 76.5 76.7 76.7 76.7
- Width (silenced/super silenced) [inch] 63.6 63.6 63.6 80.5 80.5 80.5
– Depth [inch] 38.9 38.9 38.9 41.9 41.9 41.9
Weight
– silenced [lbs.] 1856 1858 2191 2601 2778 2994
– super silenced [lbs.] - 1924 2257 2712 2888 3104
Air cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 64 / - 73 / 71 74 / 72 77 / 71 79 / 73 80 / 73
Measurement surface
– silenced / super silenced [dB(A)] 15 / - 15 / 16 15 / 16 16 / 17 16 / 17 16 / 17
Sound power level
– silenced / super silenced [dB(A)] 79 / - 88 / 87 89 / 88 93 / 88 95 / 90 96 / 90
Water cooling
Max. sound pressure level [±3 dB(A)]
– silenced / super silenced [dB(A)] 63 / - 72 / 70 73 / 71 76 / 70 78 / 72 79 / 72
Measurement surface
– silenced / super silenced [dB(A)] 15 / - 15 / 16 15 / 16 16 / 17 16 / 17 16 / 17
Sound power level
– silenced / super silenced [dB(A)] 78 / - 87 / 86 88 / 87 92 / 87 94 / 89 95 / 89
Compressor
Max.final compression temperature [°F] + 230 + 230 + 230 + 230 + 230 + 230
Volume flow according to
ISO 1217 appendix C at:
– p
max
= 100 psig [cfm]
192.24 244.83 269.10 286.76 352.02 474.70
– p
max
= 115 psig [cfm]
183.97 228.81 257.76 272.95 336.86 451.97
– p
max
= 125 psig [cfm]
183.97 228.81 257.76 272.95 336.86 451.97
– p
max
= 150 psig [cfm]
167.02 204.80 230.57 240.46 298.02 386.64
– p
max
= 190 psig [cfm]
140.18 175.14 195.97 207.98 256.35 335.80
Drive motor
Rated power [Hp] 40 50 60 60 74 101
Rated speed
– 60 Hz [rpm] 3600 3600 3600 3600 3600 3600
Protection type IP TEFC TEFC TEFC TEFC TEFC TEFC
ISO class FFFFFF
Electrical connection
Mains voltage compressor
1)
[V]
1)
Standard equipment. Mains voltages and frequencies are specified on a plate in the switch cabinet.
208 / 230 /
460 / 575
230 / 460 / 575 460 / 575 460 / 575 460 / 575 460 / 575
Frequency
1)
[Hz]
60 60 60 60 60 60
Fuse protection for 208 V
2)
[A]
150-----
Fuse protection for 230 V
2)
[A]
2)
Use fuse RK 5 only. The fuse values change in the case of other mains voltages and frequencies.
125 175 - - - -
Fuse protection for 460 V
2)
[A]
60 70 90 90 125 150
Fuse protection for 575 V
2)
[A]
50 60 70 70 90 125
