Installation 3.3 Installation
Page 36 Operating instructions for S 40-3...S 150-3 series screw compressors
3.3 Installation
General information
BOGE compressor units are supplied ready for connection. Only the work
described in the following paragraphs needs to be carried out during the in-
stallation.
– Please inspect the compressor immediately after delivery and direct dam-
age claims to the last haulier – even if the packing is not damaged! To safe-
guard claims against the haulier we recommend leaving the machine, de-
vices and packing material in the same condition as they were in when the
damage was detected.
– Prior to commissioning, check the compressor for external damage due to
transport.
– Observe the compressor very closely during commissioning and the follow-
ing trial run.
– If malfunctions occur, switch off the compressor immediately and inform
the BOGE's service department.
Checking the scope of
delivery
The scope of delivery depends on your order.
Prior to commissioning, please check whether all the parts required have been
delivered. Please check the order confirmation for any possible accessory
equipment.
The scope of delivery includes the following component parts:
– Operating instructions
– Switch cabinet key
– Electric circuit diagram (in the compartment of the switch cabinet)
– List of electrical equipment (in the compartment of the switch cabinet)
– Spare parts list
Installing the compres-
sor
1. Remove the packaging around and inside the compressor.
2. Install the compressor and align it horizontally. The compressor must stand
firmly on the ground on all feet.
WARNING!
Any installation work must only be carried out by appropriately trained per-
sons or specialists (BOGE service personnel).
Lay all energy supply lines in a trip-proof and barrier-free manner so that
potential accidents are avoided!
Prior to delivery, each compressor is subjected to a trial run in the factory.
It is carefully tested and set. However, the possibility of damage occurring
during transport cannot be excluded.
WARNING!
The compressor may only be set in operation if the rubber feet have been
fitted! If the feet have been removed for transportation, it is essential that they
be fitted again before the compressor is set in operation!
