Bomag BPH 80/65 - Dimensions; Weights

Technical Data
BOMAG 8 BPH 80/65
Fig. 4
*
BPH 80/65
Dimensions
(L) Overall length mm 2330
(L1) Length of base plate mm 1080
(W) Overall width mm 650
(W1)Widthwithextension
plates
mm 800
(W2)Widthwithextension
plates
mm 950
(H) Lowest passing height mm 785
(H1) Max. height with ex-
treme position of steering
rod
mm 1630
Weights
Basic weight kg 775
Operating weight (CECE)
with wear plates
kg 780
Operating weight (CECE)
with extension plates
kg 799
