Bomag BPR 35/60 D - 6-Monthly Maintenance: Dry Air Filter Replacement

Maintenance every 6 months
BOMAG 49 BPR 35/40 D BPR 35/60 D
Fig. 57
l Insert the fastening bracket into the opening in
the exhaust screen and screw the fastening
nut for approx. 1 turn (Fig. 57).
Fig. 58
l Slide the exhaust screen on with the fastening
bracket (Fig. 58).
l Hook the fastening bracket into the bore and
tighten the fastening nut.
5.18 Changing the dry air filter
Fig. 59
l Remove the air filter cover (Fig. 59).
Fig. 60
l Unscrew the knurled nut and take the air filter
cartridge out (Fig. 60).
!
Caution
No dirt or foreign particles must enter the
clean air side.
Do not blow the filter housing out with com-
pressed air.
l Clean the inside of the filter housing only with
a clean cloth.
l Clean the cover thoroughly.
