Example:
The following warning status is displayed:
A008D Ixt IxtLt Tc PTC
The warning status results from the hexadecimal sum of the warning
codes (0001+0004+0008+0080 = 008D).
The short-
term overload (1 s), warning limit heat sink temperature and
warning limit motor temperature warnings are present.
Output signals
The output of a warning message is signaled.
169 -
General Warning
1)
The output of a warning message in Warnings 269 is
signaled.
11 -
Warning, General
2)
1)
For linking with inverter functions
2)
For digital output
Meaning of code displayed by parameter Application Warning Status 367:
Code
Warning Status
A
00
00
NO WARNING
No warning message present.
A
00
01
BELT
Warning V-belt by Operation mode 581.
A 00 02 SW-LIM CW
The positive SW limit switch was reached (parameter
Positive SW limit switch 1145).
A 00 04 SW-LIM CCW
The negative SW limit switch was reached (parameter
Negative SW limit switch
1146).
A 00 08 HW-LIM CW The positive HW limit switch was reached.
A 00 10 HW-LIM CCW The negative HW limit switch was reached.
A 00 20 CONT
The contouring error monitoring range adjusted with
parameter Warning Threshold 1105 was left.
A 00 40 Enc
A connected encoder with data track triggered a warn-
ing.
A 00 80 User 1
The signal set on digital input User Warning 1 1363 is
active.
A 01 00 User 2
The signal set on digital input User Warning 2 1364 is
active.
Output signals
The output of an application warning message is signaled.
216 -
Application Warning
1)
The output of a warning message in Application
Warnings 273 is signaled.
26 -
Warning, Application
2)
1)
For linking with inverter functions
2)
For digital output
274 Operating Instructions ACU 06/13
