BONFIGLIOLI ACTIVE Cube ACU 401-19 User Manual

Error List
No.
Description
Unit
Display range
Chapter
310 Last error h:m; F 00000:00; FXXXX
20.1
311 Last error but one h:m; F 00000:00; FXXXX
20.1
312 Error 3 h:m; F 00000:00; FXXXX
20.1
313 Error 4 h:m; F 00000:00; FXXXX
20.1
314
Error 5
h:m; F
00000:00; FXXXX
20.1
315
Error 6
h:m; F
00000:00; FXXXX
20.1
316
Error 7
h:m; F
00000:00; FXXXX
20.1
317
Error 8
h:m; F
00000:00; FXXXX
20.1
318
Error 9
h:m; F
00000:00; FXXXX
20.1
319
Error 10
h:m; F
00000:00; FXXXX
20.1
320 Error 11 h:m; F 00000:00; FXXXX
20.1
321 Error 12 h:m; F 00000:00; FXXXX
20.1
Error List
322
Error 13
h:m; F
00000:00; FXXXX
20.1
323
Error 14
h:m; F
00000:00; FXXXX
20.1
324
Error 15
h:m; F
00000:00; FXXXX
20.1
325 Error 16 h:m; F 00000:00; FXXXX
20.1
Error Environment
330
DC –Link Voltage
V
0.0 ... U
dmax
20.2
331
Output voltage
V
0.0 ... U
FUN
20.2
332
Stator frequency
Hz
0.00 ... 999.99
20.2
333
Encoder 1 Frequency
Hz
0.00 ... 999.99
20.2
335 Phase current Ia A 0.0 ... I
max
20.2
336 Phase current Ib A 0.0 ... I
max
20.2
337 Phase current Ic A 0.0 ... I
max
20.2
338 R.m.s current A 0.0 ... I
max
20.2
339
Isd / reactive current
A
0.0 ... I
max
20.2
340
Isq / active current
A
0.0 ... I
max
20.2
341
Rotor magnetizing current
A
0.0 ... I
max
20.2
342
Torque
Nm
± 9999.9
20.2
343
Analog input MFI1A
%
±
100.00
20.2
346
Analog output MFO1A
V
0.0 ... 24.0
20.2
349 Repetition frequency output Hz 0.00 ... 999.99
20.2
350 Status of digital inputs - 00 ... 255
21.2
351 Status of digital outputs - 00 ... 255
21.2
352 Time since release
h:m:s.ms
00000:00:00.000
20.2
353
Heat sink temperature
deg.C
0 ... T
kmax
20.2
354
Inside temperature
deg.C
0 ... T
imax
20.2
355
Controller Status
-
C0000 ... CFFFF
21.3
356
Warning Status
-
A0000 ... AFFFF
21.4
357
Int. value 1
-
±
32768
20.2
358
Int. value 2
-
±
32768
20.2
359 Long value 1 -
± 2147483647
20.2
360 Long value 2 -
± 2147483647
20.2
361 Checksum - OK / NOK
20.2
Error List
362
No. of errors
-
0 ... 32767
20.1
363
No. of self acknowledged errors
-
0 ... 32767
20.1
06/13 Operating Instructions ACU 277
