BONFIGLIOLI ACTIVE Cube ACU 401-19 User Manual

Traverse function
No.
Description
Unit
Setting range
Chapter
435 Operation mode - Selection
18.8
436
Acceleration Time
s
0.01 … 320.00
18.8
437
Deceleration Time
s
0.01 … 320.00
18.8
438
Traverse Amplitude
%
0.01 … 50.00
18.8
439
Proportional Step
%
0.01 … 50.00
18.8
Technology Controller
440
Operation mode
-
Selection
17.3
441
Fixed frequency
Hz
-999.99 ... 999.99
17.3
442
max. P component
Hz
0.01 ... 999.99
17.3
443
Hysteresis
%
0.01 ... 100.00
17.3
444 Amplification - -15.00 ... 15.00
17.3
445 Integral time ms 0 ... 32767
17.3
446
Ind. volume flow control factor
-
0.10 ... 2.00
17.3
Block Frequencies
447
1. blocking frequency
Hz
0.00 ... 999.99
14.9
448 2. blocking frequency Hz 0.00 ... 999.99
14.9
449 Frequency hysteresis Hz 0.00 ... 100.00
14.9
Multifunctional input 1
450
Tolerance band
%
0.00 ... 25.00
15.1.1.3
451 Filter Time Constant ms Selection
15.1.1.4
452 Operation mode - Selection
15.1
453
Error/warning behavior
-
Selection
15.1.1.5
454
Point X1
%
0.00 ... 100.00
15.1.1.1
455
Point Y1
%
-100.00 ... 100.00
15.1.1.1
456
Point X2
%
0.00 ... 100.00
15.1.1.1
457
Point Y2
%
-100.00 ... 100.00
15.1.1.1
Positioning
458
Operation mode
-
Selection
12.6
459
Signal source
-
Selection
12.6.1
460
Positioning distance
U
0.000 ... 1 10
6
12.6.1
461 Signal correction ms -327.68 ... 327.67
12.6.1
462 Load correction - -32768 ... 32767
12.6.1
463
Activity after positioning
-
Selection
12.6.1
464
Waiting time
ms
0 ... 3.6 10
6
12.6.1
Temperature Adjustment
465 Operation mode - Selection
18.7.2
466
Temperature coefficient
%/100
0.00 ... 300.00
18.7.2
467
Adjusting temperature
deg.C
-50.0 ... 300.0
18.7.2
Positioning
469 Reference orientation ° 0.0 ... 359.9
12.6.2
471
Positioning frequency
Hz
1.00 ... 50.00
12.6.2
472
Max. positional error
°
0.1 ... 90.0
12.6.2
Motor Potentiometer
473 Ramp Keypad Motorpoti Hz/s 0.01 ... 999.99
14.10.3
474 Operation mode - Selection
14.10
Frequency reference channel
475
Reference frequency source
-
Selection
14.4
Reference percentage channel
476
Reference percentage source
-
Selection
14.5
280 Operating Instructions ACU 06/13
