BONFIGLIOLI active Installation Manual

10 11/06
4.1.1 ACT/ACU 201 (0.55 to 3.0 kW, 230 V)
Type designation
ACT/ACU 201 -05 -07 -09 -11 -13 -15
Motor-side output
Recommended
motor shaft output
P kW 0.55 0.75 1.1 1.5 2.2 3.0
Mains-side input
Nominal voltage
U
V 230
Energy dissipation,
heat sink [2 kHz]
P
v
W 43 53 73 84 115 170
Energy dissipation,
interior
P
v int
W 12 15 18 21 25 31
Thermal resistance
Thermal resistance
R
th
K/W
0.93 0.75 0.55 0.48 0.35 0.24
Mechanical
Dimensions
HxWxD
mm 190x82x140 250x85x140
Heat sink HxW mm 170x82 230x85
T
k max
–T
U
ΔT K 40
4.1.2 ACT/ACU 201 (4.0 to 9.2 kW, 230 V)
Type designation
ACT/ACU 201 -18 -19 -21 -22
Motor-side output
Recommended
motor shaft output
P kW 4.0 5.5 7.5 9.2
Mains-side input
Nominal voltage
U
V 230
Energy dissipation,
heat sink [2 kHz]
P
v
W 200 225 310 420
Energy dissipation,
interior
P
v int
W 35 48 61 68
Thermal resistance
Thermal resistance
R
th
K/W
0.20 0.18 0.13 0,10
Mechanical
Dimensions
HxWxD
mm 250x125x144 250x150x144
Heat sink HxW mm 230x125 230x150
T
k max
–T
U
ΔT K 40
