BONFIGLIOLI active Installation Manual

11/06 7
2.3 ACT/ACU 401 (0.55 to 4.0 kW, 400 V)
Type designation
ACT/ACU 401 -05 -07 -09 -11 -12 -13 -15 -18
Motor-side output
Recommended
motor shaft output
P kW 0.55 0.75 1.1 1.5 1.85 2.2 3.0 4.0
Mechanical
Dimensions
HxWxD
mm 190x82x140 250x85x140
Weight (approx.) m kg 1.2 1.6
Type of protection - - IP20 (EN60529)
Installation position - - vertical
Environmental conditions
Energy dissipation
(at 2 kHz switching
frequency)
P W 40 46 58 68 68 87 115 130
Coolant temperature Tn °C 0 ... 40 (3K3 DIN IEC 721-3-3)
2.4 ACT/ACU 401 (5.5 to 15.0 kW, 400 V)
Type designation
ACT/ACU 401 -19 -21 -22 -23 -25
Motor-side output
Recommended
motor shaft output
P kW 5.5 7.5 9.2 11.0 15.0
Mechanical
Dimensions
HxWxD
mm 250x125x144 250x150x144
Weight (approx.) m kg 2.2 3.1
Type of protection - - IP20 (EN60529)
Installation position - - vertical
Environmental conditions
Energy dissipation
(at 2 kHz switching
frequency)
P W 145 200 225 240 310
Coolant temperature Tn °C 0 ... 40 (3K3 DIN IEC 721-3-3)
2.5 ACT/ACU 401 (18.5 to 30.0 kW, 400 V)
Type designation
ACT/ACU 401 -27 -29 -31
Motor-side output
Recommended
motor shaft output
P kW 18.5 22.0 30.0
Mechanical
Dimensions
HxWxD
mm 250x225x171
Weight (approx.) m kg 8.0
Type of protection - - IP20 (EN60529)
Installation position - - vertical
Environmental conditions
Energy dissipation
(at 2 kHz switching
frequency)
P W 420 470 750
Coolant temperature Tn °C 0 ... 40 (3K3 DIN IEC 721-3-3)
