1 Scope of Supply for Devices in "Cold Plate" Variant
he scope of supply of the "Cold Plate" variant differs from the scope defined in the
operatin
instructions as re
ards the heat sink desi
n and the standard fixtures which
are not required in this variant.
1.1 ACT/ACU 201 (up to 3.0 kW) and ACT/ACU 401 (up to
4.0 kW)
Scope of Supply
Scope of supply
A
Frequency inverter
B
Terminal bar X1 (Phoenix ZEC 1,5/ST7,5)
Plug-in terminals for mains connection and DC networking
C
Terminal bar X10 (Phoenix ZEC 1,5/3ST5,0)
Plug-in terminals for relay output
D
Instructions and installation instructions for the device in "Cold Plate" variant,
CD ROM with manuals
E
Terminal bar X2 (Phoenix ZEC 1,5/ST7,5)
Plug-in terminal for braking resistor and motor connection
F
Control terminals X210A / X210B (Wieland DST85/RM3,5)
Plug-in terminal for connection of control signals
Note: Immediately check the
oods received for quality, quantity and type.
Obvious defects such as exterior dama
e of the packin
and/or the uni
must be notified to the sender within seven days for insurance reasons.
