Quick Start Guide
Agile 40 05/2013
Warnin
g
s
Frequency inverter overloaded. Check load behavior. Check motor parameters and
application parameters.
Overtemperature. Check coolin
g
, fan and ambient temperature.
Max. motor temperature reached, check motoer and sensor.
Mains phase failure, chec
k
mains fuses and supply cable.
Limit frequency reached, output frequency is limited.
Input si
g
nal at X12.3 is too low. Increase the value.
Input si
g
nal at X12.4 is too low. Increase the value.
DC link volta
g
e has reached the type- specific minimum.
- Press ESC to hide an error message. It is displayed again after 10 seconds.
- Press STOP to acknowledge an error message or a warning message. Remove the fault. It is
recommended to check the entered data.
Extended settings of control terminals
Multifunction input
X12.3 P452 1-voltage 0...10 V
X12.4 P562 2-current 0...20 mA
3-digital NPN (active: 0 V)
4-digital PNP (active: 24 V)
5-current 4...20 mA
6-voltage, characteristic
7-current, characteristic
6-: programmable characteristic via P454...457
7-: programmable characteristic via P564...567
Refer to operating instructions manual.
P: Parameter
Digital Input/ Output
X11.6 P558 0-input (default)
1-output
Multifunction output
X13.6 P550 1-digital MFO1D (P554*)
10-analog PWM MFO1A (default)
(P553*)
20-repetition frequency MFO1F
(P555*)
30-pulse train MFO1F (P557**)
Default:
1-: signal when output frequency exceeds 3 Hz (P510)
10-: output of voltage proportional to speed.
20-: frequency output 0...24 V proportional to speed
30-: output pule train, scaled by P557.
* select a signal for the output.
** Scaling
logic switchable digital inputs
X11.4 P559 0-NPN (active: 0 V)
X11.5 1-PNP (active: 24V)
X11.6
X12.1
X12.2
X12.3 P452 3- digital input NPN (active: 0 V)
4- digital input PNP (active: 24 V)
X12.4 P562 3- digital input NPN (active: 0 V)
4- digital input PNP (active: 24 V)
NPN: LOW-switching (on negative signal). Default of P562.
PNP: HIGH-switching (on positive signal). Default of P559.
Applications via control terminals
Enable X11.3
X13.3
Digital signals at both terminals
Change
direction of
rotation
X11.4
X11.5
Start clockwise by rising edge of the signal
Start anti clockwise by rising edge of the signal
Set motor
speed
X12.3 Reference speed: DC 0 ... 10 V at analog input. P452=1-voltage
(default). DC 0 V corresponds to 3,50 Hz (default value of P418).
DC 10 V corresponds to 50 Hz (default value of P419).
A000
1
A0004
...
A0008 A001
0
,
A008
0
A0
1
00
A
0
4
00
A
0800
A100
0
A400
0
