Output currents in function of PWM frequency (parameter F_12):
4kHz - 7.2kHz
(F_12 = 1...4)
8kHz
(F_12 = 5)
10kHz
(F_12 = 6)
12kHz
(F_12 = 7)
14.4kHz
(F_12 = 8)
15kHz
(F_12 = 9)
16kHz
(F_12 = 10)
SYN10 S 220 01 AF 1.4 A 1.4 A 1.3 A 1.3 A 1.2 A 1.1 A 1.1 A
SYN10 S 220 03 AF 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A
SYN10 S 220 05 AF 4.2 A 4.2 A 4.2 A 4.1 A 4.1 A 4 A 4 A
SYN10 S 220 07 AF 7.5 A 7.5 A 7.5 A 7.5 A 7.5 A 7.5 A 7.5 A
SYN10 S 220 09 AF 10.5 A 10.5 A 10 A 9.8 A 9.4 A 9.3 A 9 A
SYN10 T 400 05 AF 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A 2.3 A
SYN10 T 400 07 AF 3.8 A 3.8 A 3.8 A 3.8 A 3.8 A 3.8 A 3.8 A
SYN10 T 400 09 AF 5.2 A 5.2 A 5.2 A 5.2 A 5.2 A 5.2 A 5.2 A
36

BONFIGLIOLI Vectron Syn10 S115 01 Specifications

General

Category	Controller
Model	Vectron Syn10 S115 01
Frequency range	50/60 Hz
Protection class	IP20
Communication interface	CANopen
Relative humidity	< 95 % (non-condensing)
