SensUP Off
(1/30 [1/25] shutter);
High Sensitivity Off
0.12 lux
(0.011 fc)
0.3 lux
(0.028 fc)
SensUP On, max.
(0.25 sec. shutter);
High Sensitivity On
3
0.005 lux
(0.0005 fc)
0.011 lux
(0.001 fc)
Electronic Shutter Speed
(AES)
1/1 to 1/10000 s, 22 steps
Wide Dynamic Range (WDR) 86 dB (WDR on)
Signal-to-Noise Ratio (SNR) > 50 dB (AGC off, Weighting ON)
Backlight Compensation On/Off
White Balance ATW, Indoor, Outdoor, AWB Hold,
Extended ATW, Manual, Outdoor Auto,
Sodium Lamp Auto, Sodium Lamp
Day/Night Monochrome, Color, Auto
1. F1.6, maximum AGC. Normal light source (Halogen lamp).
2. Tinted bubble adds 0.8 f-stop loss.
3. Measured using ND1 + ND4 filters and recalculated with the transmission factor at 0.0025.
Mechanical
In-Ceiling Pendant
Pan Range 360° cont. 360° cont.
Tilt Angle 1° above horizon 18° above horizon
Pre-position Speed Pan: 400°/s
Tilt: 300°/s
Pan: 400°/s
Tilt: 300°/s
Pan/Tilt Modes
• Turbo Mode
(Manual Control)
Pan: 0.1°/s – 400°/s
Tilt: 0.1°/s – 300°/s
• Normal Mode 0.1°/s-120°/s 0.1°/s-120°/s
Preset
Accuracy
± 0.1° typ. ± 0.1° typ.
Electrical
In-Ceiling Pendant
Input Voltage 21-30 VAC,
50/60 Hz (class
II);
High PoE (with
Bosch
NPD-6001A
Midspan);
PoE+ (IEEE
802.3at, class 4
standard)
21-30 VAC, 50/60 Hz; (class
II)
High PoE (with Bosch
NPD-6001A Midspan)
or
[PoE+ (IEEE 802.3at, class 4
standard)]
4
Power
Consumption,
typical
24 W / 44 VA 60 W / 69 VA (heaters on)
or
24 W / 44 VA
(heaters off)
5
4. When used indoors, not powering heater.
5. Without heater connected in power supply box for indoor applications.
Surge Suppression
Protection on
Alarm Inputs
Peak current 17 A, peak power 300 W
(8/20 μs)
Protection on
Alarm Outputs
Peak current 2 A, peak power 300 W
(8/20 μs)
Protection on
Relay Output
Peak current 7.3 A, peak power 600 W
(10/1000 μs)
Protection on Power
Input (Dome)
Peak current 7.3 A, peak power 600 W
(10/1000 μs)
Protection on Power
Output (Arm Power
Supply)
Peak current 21.4 A, peak power 1500 W
(10/1000 μs)
10/100 Ethernet
Data Lines
Peak current 14 A, peak power 200 W
(8/20 μs)
Software Control
Camera Setup/
Control
Via web browser (such as Internet Explorer
version 7.0 or later), Bosch Configuration
Manager, Bosch Video Management System
(BVMS), or Bosch Video Client (BVC)
Software Update Network firmware upload
Network
Video compression H.264 (ISO/IEC 14496‑10), M‑JPEG
Encoding / Streaming
H.264 MJPEG
Scenario
Stream 1 Stream 2 Stream 3 Stream 4
1 Full HD
1080p30
Full HD
1080p5
I-frame
only from
Stream 1
1080p
2 Full HD
1080p30
HD 720p10 I-frame
only from
Stream 1
1080p
3 Full HD
1080p30
Downscaled
stream
I-frame
only from
Stream 1
1080p
4 Full HD
1080p30
Copy of
Stream 1
I-frame
only from
Stream 1
1080p
5 HD 720p60 HD 720p8 I-frame
only from
Stream 1
720p
6 HD 720p30 HD 720p30 I-frame
only from
Stream 1
720p
7 HD 720p30 Downscaled
stream
I-frame
only from
Stream 1
720p
5 | AUTODOME 7000 HD
