Optical Fiber
Compatibility, SMF
8–10/125 µm SMF. Must meet or exceed
fiber standard ITU-T G.652.
Optical Distance
Specifications
Specified transmission distances are limited to
the optical loss of the fiber and any additional
loss introduced by connectors, splices, and
patch panels. The modules are designed to
operate over the entire optical loss budget
range, so they do not require a minimum loss
in order to operate.
Miscellaneous
Sectors/Titling 16 independent sectors with a 20-character
title/sector
Masking 24 individually configurable privacy masks
Pre-positions 256, each with a 20-character title
Guard Tours Two (2) types of tours:
• Recorded tours – two (2)
• Preset tour – one (1), consisting of up to
256 scenes, consecutively
Supported
Languages
English, Chinese, Dutch, French, German,
Italian, Japanese, Polish, Portuguese, and
Spanish
User Connections
Power, Camera RJ-45 10/100 Base-TX Ethernet (High
Power-over-Ethernet (High PoE)) or PoE+
(IEEE 802.3at, class 4 standard)
21-30 VAC, 50/60 Hz
Power, Heater RJ-45 10/100 Base-TX Ethernet (High
Power-over-Ethernet (High PoE))
21-30 VAC, 50/60 Hz
Video and Control RJ-45 10/100 Base-TX Ethernet
Alarm Inputs (7) 2 supervised; 5 non-supervised
Programmable for “normally open” or
"normally closed"
Alarm Outputs (4) 1 dry contact relay; 3 open collector/
transistor outputs
32 VDC @ 150 ma max.
Audio 1 x mono line in, 1 x mono line out
• Signal line in 12 kOhm typical, 1 Vrms max
• Signal line out 1 Vrms at 1.5 kOhm, typical
Environmental
In-Ceiling (with acrylic
bubble)
Pendant (with acrylic
bubble)
Ingress
Protection
Rating/
Standard
IP54, Plenum rated IP66,
, NEMA
4X
7
NEMA 4X for:
• Access to Hazardous parts
• Ingress of solid foreign objects (falling dirt,
circulating dust, settling dust)
• Ingress of water (dripping and light splashing,
hosedown and splashing)
• Corrosive agents
Operating
Temp.
-10 °C to 40 °C
(14 °F to 104 °F)
-40 °C to 55 °C
(-40 °F to 131 °F)
or
-10 °C to 55 °C
(14 °F to 131 °F)
8
Storage
Temp.
-40 °C to 60 °C
(-40 °F to 140 °F)
-40 °C to 60 °C
(-40 °F to 140 °F)
Humidity 0% to 90% relative, non-
condensing
0% to 100% relative,
condensing
7. Meets requirements for NEMA 4X, except impact test, with use of an acrylic bubble.
8. Without heater connected in power supply box for indoor applications.
Construction
Dimensions See dimensional drawings
Weight
• In-ceiling 2.58 kg (5.69 lb)
• Indoor/Outdoor
Pendant
3.06 kg (6.75 lb)
Bubble Size 153.1 mm diameter (6.03 in.)
Construction Material
• Housing In-ceiling: Magnesium
Pendant: Cast aluminum
• Bubble In-ceiling: HD High-resolution acrylic
Pendant: High-resolution acrylic
Standard Color White (RAL 9003)
Standard Finish Powder coated, sand finish
Mounts/Accessories
Bubbles
In-ceiling
Clear HD high-resolution acrylic VGA-BUBHD-CCLA
Tinted HD high-resolution acrylic
(Included with in-ceiling camera models.)
VGA-BUBHD-CTIA
Pendant
Clear high-resolution acrylic
(Included with pendant camera models.)
VGA-BUBBLE-PCLA
Tinted high-resolution acrylic VGA-BUBBLE-PTIA
Polycarbonate bubbles are not recommended for use with HD products
because of optical degradation.
Pendant Arm Mounts
Wall Arm (No Transformer) VG4-A-PA0
Wall Arm (120/230 VAC Transformer) VG4-A-PA1 /
VG4-A-PA2
Pendant Arm with Wiring VGA-PEND-ARM
Mounting plate for VGA-PEND-ARM VGA-PEND-WPLATE
Trim skirt for VG4 Series Power Supplies VG4-A-TSKIRT
7 | AUTODOME 7000 HD
