Optional Mounting Plates for Arm Mounts
Corner Mounting Plate VG4-A-9542
Mast (Pole) Mounting Plate VG4-A-9541
Pendant Pipe Mounts
Pipe Mount Cap VG4-A-9543
Pendant Roof Mounts
Roof (Parapet) Mount
(VG4-A-9543 Pipe Mount Cap required. Available separately.)
VGA-ROOF-MOUNT
Optional Mounting Plates for Roof Mounts
Flat Roof Adapter for Parapet Mount LTC 9230/01
In-ceiling Support Kits
Bracket for suspended or drop ceilings VGA-IC-SP
Power Supplies
High PoE Midspan 60W, single port, AC in NPD-6001A
Outdoor Power Supply Box, no transformer VG4-A-PSU0
Outdoor Power Supply Box (120/230 VAC
Transformer)
VG4-A-PSU1 /
VG4-A-PSU2
Fiber Optic Kit VG4-SFPSCKT
Dimensional Drawings
AUTODOME 7000 – Slot for SD card
1 Slot for SD card
mm
[in.]
134.6
[5.30]
366.9
[14.44]
11.0
[0.43]
160.0
[6.30]
186.1
[7.33]
169.9
[6.69]
188.0
[7.40]
158.0
[6.22]
R 76.6
[3.01]
189.0
[7.44]
224.0
[8.82]
549.6
[21.64]
532.1
[20.95]
469.1
[18.47]
201.2
[7.92]
216.4
[8.52]
233.0
[9.17]
22.86
[0.90]
86.7
[3.42]
299.4
[11.79]
R 76.6
[3.01]
189.0
[7.44]
224.0
[8.82]
AUTODOME 7000 Dimensions – Pendant, Pipe
1 Power supply box and
sunshield
4 Power supply box
2 Sunshield removed 5 Trim skirt
3 Mounting plate
206.89
[8.145]
175.99
[6.929]
21.29
[0.838]
99.76
[3.928]
IP
78.04
[3.072]
IP
204.49
[8.051]
ø
74.65
[2.939]
HD
95.88
[3.775]
HD
mm
[in.]
ø
AUTODOME 7000 Dimensions – In-ceiling
8
| AUTODOME 7000 HD
