stored in the camera. For total data protection, the
video and audio communication channels can be
independently AES encrypted with 128-bit keys by
installing the optional encryption site license.
Easy upgrade
Remotely upgrade the camera whenever new firmware
becomes available. This ensures up-to-date products,
thus protecting investment with little effort.
Certifications and approvals
HD standards
• Complies with the SMPTE 274M-2008 Standard in:
– Resolution: 1920x1080
– Scan: Progressive
– Color representation: complies with ITU-R BT.709
– Aspect ratio: 16:9
– Frame rate: 25 and 30 frames/s
• Complies with the 296M-2001 Standard in:
– Resolution: 1280x720
– Scan: Progressive
– Color representation: complies with ITU-R BT.709
– Aspect ratio: 16:9
– Frame rate: 25, 30, 50 and 60 frames/s
Electromagnetic
Compatibility (EMC)
Complies with FCC Part 15, ICES-003, and
CE regulations, including EN 50130-4, EN
55022 Class A, EN 61000-3-3, EN
61000-6-1, EN61000-6-2, and EN 50121-4
(Railway applications)
Product Safety Complies with CE regulations, UL, CSA, EN,
and IEC Standards
EN60950-1
Environmental In-ceiling: IP54, Plenum rated (with acrylic
bubble)
Indoor/Outdoor pendant: IP66, NEMA 4X
ONVIF conformance EN-50132-5-2
Notice
Conformity to EN 50130-4
One of the following power supply units is
required to conform to the EN 50130-4 standard:
VG4-A-PSU0, VG4-A-PSU1, VG4-A-PSU2, VG4-A-
PA0, VG4-A-PA1, or VG4-A-PA2.
Parts included
In-ceiling
Quantity Item
1 AUTODOME 7000 In-Ceiling camera with acrylic bubble
and white trim ring
1 Interface box
1 Optional black trim ring
1 Ceiling gasket (for IP54 conformance)
1 Product DVD (which includes complete Operation Manual)
1 Packet of printed Safety literature
Outdoor Pendant
Quantity Item
1 AUTODOME 7000 Pendant camera with clear acrylic
bubble and sunshield
1 Product DVD (which includes complete Operation Manual)
1 Packet of printed Safety literature
Notes:
• The pendant can be converted to an indoor pendant
by removing the sunshield.
• Mounting hardware and accessories are available
separately.
Technical specifications
20x HD Day/Night Camera
Imager 1/2.8-in.-type CMOS
Number of Pixels Effective: Approximately 3.27
megapixels
Delivered: Approximately 2 megapixels
Aspect Ratio HD: 16:9
Lens 20x optical zoom,(4.7 to 94 mm)
Focus One-push (default), Automatic
(normal, low), Manual
Iris Automatic with manual override (F1.6
to F3.5)
Field of View
• 1080p Mode 2.9° (tele) to 55.4° (wide)
• 720p Mode 2.0 (tele) to 37.6 (wide)
Minimum Working Distance Day mode: 300 mm (wide) to
1000 mm (tele)
Night mode: 10 mm (wide) to 1000
mm (tele)
Gain Control Automatic/Manual (–3 to +28 dB,
+2 dB steps/16 steps)
Digital Zoom 12x
Sensitivity (typical)
1
30 IRE
2
50 IRE
2
Day Mode
SensUP Off
(1/30 [1/25] shutter);
High Sensitivity Off
0.8 lux
(0.074 fc)
1.7 lux
(0.158 fc)
SensUP On, max.
(0.25 sec. shutter);
High Sensitivity On
3
0.04 lux
(0.004 fc)
0.08 lux
(0.007 fc)
Night Mode
4 | AUTODOME 7000 HD
