36 en | Functional Description AVENAR panel series
2020.05 | 6.0 | F.01U.347.557 Bosch Sicherheitssysteme GmbH
Notice!
Do not use tools with sharp edges (e.g. screw drivers or pens)
to operate the device or its touchscreen.
Notice!
The device may not be exposed to direct sunlight.
Notice!
Touchscreen recalibration is required to be performed at least
once a year. Otherwise operating the device may be difficult or
even not possible without prior re-calibration. For further
information, see the necessary procedure in the user guide.
2 Functional Description
The panel controller controls every component connected to the
panel and features the following functional elements (see
01,
page 4
):
Pos. Designation Function
A Interfaces CAN1, CAN2, IN1/2, Rail
B Touchscreen Operating the networked system through virtual
buttons and variable display windows
C 6 fixed
buttons
Standard entries
D Power button Shutdown and restart of the device
E Memory card
slot
Memory card reader for maintenance services
F Network label Label assigning the different network connectors
G DIP switch
label
DIP switch label with areas to write down the PNA
(Physical Node Address) and the IP address
