AVENAR panel series Installation | en 37
Bosch Sicherheitssysteme GmbH 2020.05 | 6.0 | F.01U.347.557
Pos. Designation Function
H Interface label Label including connector assignment
I 6-pin DIP
switch
DIP switch settings for CAN bus networking & panel
redundancy
J Product label Important product data
K 18 LEDs Indicating the operating status
3 Installation
The panel controllers may be mounted into the following
housings:
CPH0006A, MPH0010A, HCP0006A and HBC0010A.
For the installation, follow these instructions:
1. Make sure that the PRS-0002-C Panel Rail Short is mounted
before you start installing the Panel Controller.
2. Start assembling the hinge and the mounting bracket (see
02, page 5
).
3. Connect the ground wire to the screw on the housing (see
04, page 7
).
4. Plug the cable into the slot labeled IN of the PRS-0002-C
Panel Rail Short (see
05, page 8
).
Note: Do not plug the cable into the slot labeled OUT nor
into the slots of the PRD 0004 A Panel Rail Long
(exception: cable to redundant panel).
5. Plug the EOL resistor for the databus into the slot labeled
OUT of the last PRD 0004 A Panel Rail Long in use (see
06,
page 9
).
6. Attach the supplied label to the side of the housing (see
06,
page 9
).
