AVENAR panel series Technical Specifications | en 39
Bosch Sicherheitssysteme GmbH 2020.05 | 6.0 | F.01U.347.557
Fixing the Ethernet cables to the panel controller
The housing in which the panel controller is installed must be
open.
Lift and swing out the panel controller if already mounted.
1. Look at the back of the device.
2. Use cable ties to attach the Ethernet cables to the fixing
points as shown in the figure (see
09, page 12
).
3. Check the routing of the cables. They must not be crushed
or trapped.
P The cables are fixed to the panel controller.
Fixing the Ethernet cables to the housing
The housing in which the panel controller is installed must be
open.
Lift and swing out the panel controller if already mounted.
1. Look at the top area of the housing.
2. Use cable ties to attach the Ethernet cables to the fixing
points as shown in the figure (see
10, page 13
).
3. Check the routing of the cables. They must not be crushed
or trapped.
P The cables are fixed to the housing.
5 Technical Specifications
Electrical
Current consumption (mA at
24 VDC)
– standby: 170
– alarm: 400
Maximum power loss (W) 10
