Bosch AVENAR Series - Mechanical Specifications; Environmental and Storage Conditions

40 en | Technical Specifications AVENAR panel series
2020.05 | 6.0 | F.01U.347.557 Bosch Sicherheitssysteme GmbH
Max. CAN cable length in
networks
Lmax = 1000 m, depending on
configuration, cable type and
topology
Mechanical
Housing material Polycarbonate (PC)
Color RAL7016, Anthracite
Weight (kg) 2.4
Dimensions H x W x D (mm) 190x404x60
Flammability rating UL94-V0
LCD display (pixels) 800x480
Operating and display
elements
– 6 keys
– 18 LEDs
Interfaces CAN1, CAN2, ETH1, ETH2,
ETH3, ETH4, USB , Rail
Signal inputs IN1/IN2
Environmental
Protection class as per EN
60529
IP 30
Permissible operating
temperature (°C)
-5to+50
Relative humidity at 25°C (%) ≤95 (non-condensing)
Storage
Permissible storage
temperature (°C)
-20to+70
