Table 5.1: B450 networking parameters configurable in RPS
Notice!
If you are using a GV4 version 1.00 control panel, select “B420 Ethernet Communicator”
within RPS. If you are using a GV4 v2.00 control panel or higher, or a B Series control panel,
select ”B426 Ethernet Communicator” within RPS.
Information about the B450 such as it's Status, IP Address, Bus Voltage and the assigned
phone number of the plug-in module can be found on the RPS Diagnostics screen for the B42X
module per figure 5.2. The plug-in communicator's phone number is displayed in the
"Hostname" field. Refer to the illustration below.
Figure 5.3: B450 status shown as Ethernet Communicator in RPS Diagnostics with GV4 version 1.00
Conettix Plug-in Communicator
Interface
Configuration | en 21
Bosch Security Systems, Inc. Installation and Operation Guide 2013.09 | 02 | F.01U.282.875
