USB Main menu
1
2
3
4
Figure 5.9: USB Main Menu
Callout Description
1 Installed device
2 Current device status
3 Current access level
4 Main menu options
The USB main menu appears:
– after a user enters a password successfully
– every time the user presses [Enter] without first selecting an option from the main screen
– upon returning from a sub-menu.
USB menu structure
The following illustration depicts the B450 menu structure.
5.3.3
5.3.4
Conettix Plug-in Communicator
Interface
