64 en | Keypads, keyswitches, keyfobs and transmitters Control Panels
2018.07 | 10 | F.01U.303.996 Installation Manual Bosch Security Systems, Inc.
9.3 RADION keyfobs and Inovonics pendant transmitters
The control panel supports up to 1000 wireless RADION keyfobs or 350 Inovonics pendant
transmitters.
The control panel supports two RADION keyfob models, RFKF-FB-A and RFKF-TB-A, that
communicate with the control panel using the B810 wireless receiver.
RADION keyfob FB
The RADION keyfob FB four button keyfobs are designed for arming (lock icon) and disarming
(unlock icon) the system remotely. You can configure the programmable buttons at the control
panel for additional control functionality. To operate the programmable buttons, simply press
and hold either button for at least one sec in order for the desired feature to work.
Uniquely coded arm and disarm buttons
Panic alarm
LED indicator
Programmable option buttons
RADION keyfob TB
The RADION keyfob TB two button keyfobs are designed for arming (lock icon) and disarming
(unlock icon) the system remotely. To operate these buttons, simply press and hold either
button for at least one sec in order for the desired feature to work.
Uniquely coded arm and disarm buttons
Panic alarm
LED indicator
Notice!
For specific installation and operation instructions, please refer to the RADION keyfob (RFKF-
FB-TB/RFKF-FB-TB-A) Installation Guide and the RADION receiver SD (B810) System Reference
Guide.
Custom functions and the RADION keyfob FB
Using RPS or the Installer Services Portal programming tool (available in Europe, Middle East,
Africa, and China), you can assign two custom functions to a RADION keyfob FB, allowing a
user to initiate the functions wirelessly. For more information, refer to RPS Help or the
Installer Services Portal programming tool Help.
