 Online calibration of multi-point adjustment channels
 Click on ‘Calibrate adjustment points’ to open calibration window
 Apply the desired physical condition to the sensor (e.g. by applying a force on the wheel)
 Enter the physical value in the value column of the desired calibration point (e.g. 745N)
 Press the ‘Calibrate’ button of the desired calibration point
 Repeat for all curve points
 Click ‘Close’ when done
C 60 Online Measurement
