Bosch C 60 - Page 127

127
 Online calibration of multi-point adjustment channels
 Create a multi-point adjustment measurement channel and download configuration
 Click on the channel in the project tree
 Double click a measurement channel in the data window to open the online view
C 60 Online Measurement
Internal | BEG/EMS1 CsM | 6/4/2010 | © Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
C 60 Online Measurement + Calibration
Click to open
measurement
channels in
data view
Double click to
open online
view
Click to open
calibration
window
Analog and
physical value
