126
Online calibration of multi-point adjustment channels
Example: measurement of wheel force
Physical property ‘wheel force’
not directly measureable
Load transfer through suspension kinematics
Physical value at sensor position defined by vehicle
Curve definition by online adjustment at vehicle
C 60 Online Measurement
Internal | BEG/EMS1 CsM
| 6/4/2010 | ©
Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
C 60 Online Measurement + Calibration
Force @ wheelForce @ wheel
Force @ sensor
