Diagnostic channels
Diagnosis of BT-60 is possible through channels on C 60
C 60 Recording and Telemetry
Internal | BEG/EMS1 CsM
| 6/4/2010 | ©
Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
Configuration of Burst Telemetry
C 60
connected to
BT-60
Data ready
for
transmission
Signal quality
of radio link
-55dBm: good
-70dBm: fair
-95dBm: no link
Byte counter
for data
transmission
over radio link
