C 60 Analog and Frequency Inputs
Internal | BEG/EMS1 CsM | 6/4/2010 | © Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
C 60 Analog and Frequency Inputs
 C 60 features
 24 analog inputs (with Software Upgrade 1; 6 analog inputs without upgrade)
 0…5V
 12 bit A/D converter
 Switchable 3.01kOhm pull-up resistor
 8kHz acquisition rate, up to 1kHz recording rate
 Linear phase digital filter
 4 frequency inputs (with Software Upgrade 1; no frequency inputs without upgrade)
 5V Hall-effect type, 2.5V trigger level
 20kHz max. frequency
 10ms measurement window
 4 PWM outputs
 Low-side switch
 Up to 2A each
 Output frequency selectable
