A ‘Characteristic Curve Wizard’
opens
Click ‘Next’
when done
C 60 Analog and Frequency Inputs
Internal | BEG/EMS1 CsM
| 6/4/2010 | ©
Bosch Engineering GmbH 2009. All rights reserved, also regarding any disposal, exploitation,
reproduction, editing, distribution, as well as in the event of applications for industrial property rights.
Motorsport
Configuring Inputs –
Characteristic Curve
Activate
Pull-up
Resistor in
C 60
Select
physical unit
here
Physical
(channel)
value
Choose ‘Ohm’
to
enter datasheet
values directly
Enter resistance/temperature pairs
from sensor datasheet here
(The 3.01kOhm pull-up resistor is
automatically taken into account)
