-9-
B@A9/<D – Connects the dust chute to the
dust bag. Can be rotated to direct dust.
B@A.4 – Captures chips and dust. Has zipper
at the bottom. Bag can be uncoupled from elbow or
chute for emptying.
<D2? B.?1 0AB.A6<; 6;8 –Allows for
smooth movement of the lower guard.
!.A2?6.99.:= – Used to hold the workpiece
to the table and base; insert into clamp post location
(item 29).
9.:=$<@A9<0.A6<; – Insert material clamp
post into hole prior to locking.
?B@5.=@ – Keeps motor brushes in position
and provides easy access for inspecting and replac-
ing brushes.
2C29 <08 2C2? – Locks and unlocks the
head assembly at a desired bevel angle.
2C29&0.92.;1$<6;A2?@ – Allows user to eas-
ily read bevel angles. Pointer indicates current
angle.
23A2C29&A<=@ – Adjust for 47°, 45°, and
33.9° bevel stops (crown molding setting).
H%645A2C29&A<= – Slide front or back for 0°
or -2° bevel stop to right.
?/<? <08 – Press arbor lock button to keep
blade from rotating when loosening or tightening
arbor bolt during blade removal or installation.
2.1@@2:/9F <08$6; – Used to lock the
head assembly in lower position for transporting.
FIG. 2
