10 Technical data
Gateway Connect S2
4
Based on ambient temperature +25°C and good mobile radio conditions. Depending on configuration, quantity of sensors and operating conditions.
5
The external voltage source used to operate the device must meet the requirements for LPS ("limited power source") according to IEC/EN 60950-1, section 2.5 or IEC/EN 62368-1, Annex
Q.
Dimensions (L x W x H) 136 mm x 69 mm x 36 mm
Weight ca. 480 g
Power supply
Lithium Iron Phosphate (LiFePO
4
)
3.2 V
6.8 Ah
21.76 Wh
Battery life 1800 to 5000 Uploads
4
Localization
• GNSS: Global Positioning System (GPS)
• A-GPS: supported
• Cell ID localization: Premium Cell Locate
Technology
IEEE 802.15.1
2.4 GHz
Protocol Proprietary, RX only
Range > 50 m free line of sight
Scan interval configurable
Scan duration configurable
Charging voltage
8 V to 24 V
⎓
(DC) LPS required
5
Cable length max. 3m
Charge time ca. 12 h to full charge
Data buffering capacity > 200000 data sets
Maximum number of sensors in range 1500
Cellular Connectivity
• 2G GSM/GPRS 850 / 900 / 1800 / 1900 MHz
• LTE Cat M1 (optional: Narrow Band IoT)
EU: B3 / B8 / B20
USA / Kanada: B2 / B4 / B5 / B12
SIM Integrated SIM chip
RF output power
GSM850 / EGSM900 33 dBm
DCS1800 / PCS 1900 30 dBm
LTE-FDD B2 / B3 / B4 / B5 / B8 / B12 / B20 23 dBm
Housing material PA6GF30
IP protection class IP67 (with connector mounted)
